1. Input ports: 1 x Video 2 x VGA x DVI 1 x SDI 1 x DP1.2 1 x HDMI1.4
2. 4x DVI outputs, each port’s maximal output resolution is 1920 x 1080 60Hz
3. 4K2K ultra HD video processing, single port HDMI or DP can receive 4K2K ultra HD video signal, through internal
sync processing of frequency doubling, it divided into 4 images to output, each image’s resolution is
1920 x 1080_60, pixel-to-pixel sync output to 4K2K LED screen. It can also capture a part of a signal and scale
it to be displayed on a LED screen of any size
4. Two 4K2K signals can be input at the same time, supports DP1.2 and HDMI1.4 signals, and it can realize
PIP / PBP dual display or seamless switching
5. Mixed video processing and switching :windowing and overlapping of Ultra HD(4K2K), HD(1080P), and
SD videos; Seamless switching, fade-in / fade-out
6. Input signals can be scaled in 2 times to be fully and sync displayed on a 8K2K LED screen, through
internal sync processing of frequency doubling, it divided into 8 images to output, each image’s resolution
is 1920 x 1080_60
7. Sync monitoring can use a 1080P display to monitor 4K2K input signal
8. Roaming and windowed picture on 4K2K ultra HD background picture
9. State-of-the-art motion-adaptive de-interlace processing technology; no more trailing or jagged pictures
10. CrossPoint high-bandwidth and high data-rate transmission technology
11. Seamless or fade-in/fade-out switching effect between any input signals
12. Image or text overlay supported, AIAO(Any In Any Out)allows for cropping, scaling and positioning of any size
input to any size output
13. Convenient operations, set 4K2K pixel-to-pixel sync display on LED screen by pressing a button, select
preset modes by pressing a button
14. Convenient panel / Rs232 / USB / LAN operation
